Regency HR-2B

General characteristics

HAM bands

2m

Frequency stability

?

Tuning steps

?

Memories

12 channels in 1 bank(s)

Receiver

RX-range

144-148 MHz

Modulations

FM

Sensitivity

0.35 µV

Selectivity

16 kHz @ -6 dB
32 kHz @ -50 dB

Filters

?

Receiver system

Double conversion superheterodyne

IF-frequencies

10.7 MHz / 455 kHz

Image rejection

?

Audio output

?

Transmitter

TX-range

144-148 MHz

Modulations

FM

RF-output

15 W

Connections

Antenna

-

Impedance

50 Ω

Other

-

Electrical

Power requirements

13.6 V DC

Current drain RX

180-800 mA

TX

2.9 A

Physical

Dimensions (w×h×d)

64 × 140 × 190 mm (2.52 × 5.51 × 7.48 in)

Weight

?

Form factor

Mobile

Manufactured

Between 197x and 197x

Other features

Usage

Amateur / Ham radio operators

Features + options

-

Accessories

-

RigReference ID

5976

MPN

REGENCY-HR-000002B

Manuals, diagrams and brochures

Regency HR-2B magazine ad JPEG - 640.4 kB, submitted by Pancho Cheja



Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Regency HR-2B. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Regency HR-2B is around:

• USD 12.00

Price History Chart

These estimates are based on the following prices:
