The Dragon SY-550 is also sold as the Albrecht AE550

General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
5 / 10 / 12.5 / 15 / 20 / 25 kHz
Memories
10 channels in 1 bank(s)

Receiver

RX-range
136-174 MHz
Modulations
FM
Sensitivity
0.18 µV (12 dB SINAD)
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
21.4 MHz / 455 kHz
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146(148) MHz
Modulations
FM
RF-output
High: 25 W, Low: 1 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
200 mA
TX
4.5 A max

Physical

Dimensions (w×h×d)
130 × 35 × 125 mm (5.12 × 1.38 × 4.92 in)
Weight
500 gr (1.1 lbs)
Form factor
Mobile
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
6078
MPN
DRAGON-SY-000540
