ICOM IC-7300

General characteristics

HAM bands

160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  6m  10m  4m

Frequency stability

Less than ±0.5 p.p.m. (–10˚C to +60˚C; 14˚F to 140˚F)

Tuning steps

1 Hz

Memories

101 channels in bank(s)

Receiver

RX-range

RX: 0.03-74.8 MHz (some bands not guaranteed)

Modulations

AM   FM   CW   USB   LSB   RTTY

Sensitivity

SSB/CW (at 10dB S/N)
0.5-1.8MHz: -
1.8-29.995MHz: 0.16μV
28.0-29.7MHz: -
50MHz band: 0.13μV

AM (at 10dB S/N)
0.5-1.8MHz: 12.6μV
1.8-29.995MHz: 2.0μV
28.0-29.7MHz: -
50MHz band: 1.0μV

FM (at 12dB SINAD)
0.5-1.8MHz: -
1.8-29.995MHz: -
28.0-29.7MHz: 0.5μV
50MHz band: 0.25μV

Selectivity

SSB (BW: 2.4KHz)
More than 2.4kHz/–6dB
Less than 3.4kHz/–40dB

CW (BW: 500Hz)
More than 500Hz/–6dB
Less than 700Hz/–40dB

RTTY (BW: 500Hz)
More than 500Hz/–6dB
Less than 800Hz/–40dB

AM (BW: 6kHz)
More than 6.0kHz/–6dB
Less than 10kHz/–40dB

FM (BW: 15kHz)
More than 12.0kHz/–6dB
Less than 22kHz/–40dB

Filters

?

Receiver system

Direct Sampling Superheterodyne

IF-frequencies

36 kHz

Image rejection

More than 70dB

Audio output

More than 2.5W (at 10% distortion with an 8Ω load, 1kHz)

Transmitter

TX-range

1.8-1.999 / 3.5-3.999 / 5.255-5.405* / 7-7.3 / 10.1-10.15 / 14-14.35 / 18.068-18.168 / 21-21.45 / 24.89-24.99 / 28-29.7 / 50-54 MHz

Modulations

AM   FM   CW   USB   LSB   RTTY

RF-output

SSB/CW/FM/RTTY: 2–100W, AM: 1–25W

Connections

Antenna

SO-239

Impedance

50Ω

Other

-

Electrical

Power requirements

13.8V DC ±15%

Current drain RX

0.9A typical (Standby), 1.25A (Maximum audio)

TX

21A (at 100W output power)

Physical

Dimensions (w×h×d)

240 × 94 × 238 mm (9.45 × 3.70 × 9.37 in) (projections not included)

Weight

4.20 kg (9.3 lbs)

Form factor

Base Station

Manufactured

Between 2016 and 20xx

Other features

Usage

Amateur / Ham radio operators

Features + options

Real-time spectrum scope
Built-in automatic antenna tuner
101 channels (99 regular, 2 scan edges)
SD memory card slot for saving data
Cooling fan system
Multi-function meter
CW functions: full break-in, CW reverse, CW auto tuning
SSB, CW, RTTY, AM, FM modes
Remote control via PC (RS-BA1 IP remote control software)

Accessories

-

RigReference ID

6117

MPN

ICOM-IC-007300

Manuals, diagrams and brochures

ICOM IC-7300 Basic Manual (English) PDF - 14.31 MB, submitted by RigReference

ICOM IC-7300 Full Manual (English) PDF - 25.73 MB, submitted by RigReference

ICOM IC-7300 Service (English) PDF - 13.38 MB, submitted by William



Upload relevant documents

Reviews & stories

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-7300. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-7300 is around:

• EUR 811.00 ~ EUR 787.00
• USD 766.00 ~ USD 687.00
• CAD 1198.00

Price History Chart

These estimates are based on the following prices:
