Elecraft K3S

160-6m Low-Noise SDR Transceiver

Specs Manuals (0) Reviews (0) Prices (1) Compare

Upgraded version of the Elecraft K3. Improvements include:
Ultra low-noise synthesizer for exceptional strong-signal receive
performance and transmit signal purity (KSYN3A)
• USB port–integrates remote control and line-level audio,
eliminating the need for a PC sound card and audio cables
• Second preamp for 12-6 m weak signal work (on included KXV3B
module)
• Multiple attenuators, providing steps of -5/-10/-15 dB
• Enhanced look and feel, with new LCD bezel, soft-touch VFO knob
• Lower-Loss ATU option with true bypass relay (KAT3A)
• Redesigned AF output circuitry for outstanding speaker audio
• Accurate, high-speed CW transmit even in SPLIT mode
• Coverage of the 630-meter band (~470 kHz), and lower1

General characteristics

HAM bands: 160m 80m 60m 40m 30m (WARC) 20m 17m (WARC) 15m 12m (WARC) 11m (CB) 6m 2m 10m
Frequency stability: +/- 5 p.p.m. (0-50 °C) TCXO standard; +/- 1 p.p.m. TCXO opt. (+/- 0.5 p.p.m. typ., 0-50 °C). K3EXREF option locks TCXO to an external 10-MHz reference (+/- 1 to 2 Hz typ.).
Tuning steps: 1, 10, 20, and 50 Hz fine steps; user-configurable coarse tuning steps (per-mode).
Memories: 144 channels in 1 bank(s)

Receiver

RX-range: 10-160 m + WARC / 6 m
Optional 2m / 630m
Modulations: AM FM CW USB LSB FSK AFSK RTTY PSK31/63
Sensitivity: HF, Preamp off: -133 dBm. Preamp 1: -138 dBm. Preamp 2 (12/10/6 m): -145 dBm
Selectivity: ?
Filters: 2.7 kHz + variable IF DSP Options: 200 Hz, 250 Hz, 400 Hz, 500 Hz, 1 kHz, 1.8 kHz, 2.1 kHz, 2.8 kHz, 6 kHz (AM & ESSB), & 12 kHz for FM
Receiver system: Hybrid SDR / Double conversion superheterodyne
IF-frequencies: 1st: 8.215 MHz
2nd: 15 kHz
Image rejection: ≥ 70 dB
Audio output: 2.5 W per channel into 4 ohms; typ. 10% THD @ 1 kHz, 2 W, Line level + headphones

Transmitter

TX-range: 0.5-30 / 50-54 MHz (2m option)
Modulations: AM FM CW USB LSB FSK AFSK RTTY PSK31/63
RF-output: 0.1-10 / 0.1-100

Connections

Antenna: BNC + SO-239
Impedance: 50Ω
Other: -

Electrical

Power requirements: 11-15V DC
Current drain RX: 0.9 A
TX: 17-22 A

Physical

Dimensions (w×h×d): 112 × 282 × 300 mm (4.41 × 11.10 × 11.81 in) With projections
Weight: 3.80 kg (8.4 lbs) Without options
Form factor: Base Station
Manufactured: Between 2015 and 20xx in USA

Other features

Usage: Amateur / Ham radio operators
Features + options: RS-232C / USB-B
Built in PSK, RTTY, and CW text decode/display
Built-in keyer
DVR option
Sub RX option
High-contrast LCD
Dual VFOs
Real-time clock
Accessories: -
RigReference ID: 6156
MPN: ELECRAFT-K000003S
