Similar to the ELAD FDM-DUO, but without the transmitter function.
Price when new in 2017: EUR 899.00

General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
0.02-170 MHz
Modulations
AM   AM-sync   FM   W-FM   CW   SSB   DSB   RTTY
Sensitivity
0.39 µV (CW, BW 500 Hz, 10 dB (S+N)/N)
Selectivity
>100 dB, Software defined
Filters
?
Receiver system
SDR / direct conversion
IF-frequencies
?
Image rejection
?
Audio output
?

Connections

Antenna
SO-239 + SMA
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
?
Weight
?
Form factor
Base Station
Manufactured
Between 2017 and 201x in Italy

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
6168
MPN
ELAD-FDM-DUOR

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ELAD FDM-DUOr. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic price data, today's estimated value of the ELAD FDM-DUOr in Good condition is around:

  • EUR 500

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2019 EUR 750.00 Used / Mint oe3gas
