The Whistler TRX-2 is the mobile version of the [[Rig:6174}}. It is a multi-system adaptive digital trunking scanner with Motorola P25 Phase I, X2-TDMA, Phase II and DMR making it capable of monitoring the following unencrypted channels/systems: Conventional DMR (Entered as a DMR trunked system, Hytera XPT, MotoTRBO™ Capacity Plus, MotoTRBO™ Connect Plus, and MotoTRBO™ Linked Cap Plus systems.
General characteristics
- HAM bands
- 11m (CB) 6m 2m 1.25m 70cm 33cm 23cm 10m 4m
- Frequency stability
- ?
- Tuning steps
- 3.125 / 5 / 6.25 / 7.5 / 8.33 / 10 / 12.5 / 25 kHz
- Memories
- 1000000 channels in 1 bank(s) @ 80 channels/second
Receiver
- RX-range
- 25-54 / 108-174 / 216-512 / 764-960 / 1240-1300 MHz (excl. cellular)
- Modulations
- AM FM DMR P25
- Sensitivity
- FM (12 dB SINAD unless otherwise noted)
VHF Low: 0.2 µV
VHF Aircraft (AM): 0.4 µV
VHF High 137-174 MHz: 0.3 µV
VHF High 216-300 MHz: 0.4 µV
UHF Low 300-406: 0.8 µV
UHF/UHF-T 406-512 MHz: 0.4 µV
UHF High 764-960 MHz: 0.5 µV
1240 -1300 MHz: 0.5 µV - Selectivity
- ?
- Filters
- ?
- Receiver system
- Triple conversion PLL super heterodyne
- IF-frequencies
- 1st: 380.8 MHz
2nd: 21.4 MHz
3rd: 455 kHz - Image rejection
- ?
- Audio output
- 8 Ohms Resistor Load at speaker terminal
Connections
- Antenna
- BNC
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 12-16 V DC
- Current drain RX
- ?
- TX
- -
Physical
- Dimensions (w×h×d)
- 180 × 45 × 135 mm (7.09 × 1.77 × 5.31 in)
- Weight
- 9.50 kg (21.0 lbs) without antenna
- Form factor
- Mobile
- Manufactured
- Between 2016 and 20xx in USA
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- • Functional keypad and backlit LCD display
• USA/Canada Radio Reference database on SD Card
• Quick Location based Programming (City, Zip,
County)
• Detects and masks encrypted voice audio
• Decodes Radio ID/Talkgroup ID data
• Upgradeable CPU Firmware, DSP Firmware and
Database Library
• USB Interface 2.0 or earlier
• DMR/MotoTRBO™ Tier II
• Improved P25 Functionality (Phase II, X2-TDMA)
• PC Software to customize your settings
• Signal Strength Meter
• 200 Scanlists
• Weather Radio Function - Accessories
- -
- RigReference ID
- 6174
- MPN
- WHISTLER-TRX-000002
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Whistler TRX-2. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic price data, today's estimated value of the Whistler TRX-2 in Good condition is around:
- USD 493
