Identical to the Yaesu FT-200.
General characteristics
- HAM bands
- 80m 40m 20m 15m 10m
- Frequency stability
- Less than 100 Hz per 30 minutes after warm-up
- Tuning steps
- ?
- Memories
- 6 channels in 1 bank(s)
Receiver
- RX-range
- 8-10 m
3.5-4 / 7-7.5 / 14-14.5 / 21-21.5 / 28.5-29 MHz - Modulations
- AM CW USB LSB
- Sensitivity
- 0.5 µV input S/N 10 dB
- Selectivity
- 2.4 kHz @ - 6 dB, 4 kHz @ -60 dB
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- 50 dB
- Audio output
- 1 W @ 10% distortion into 8 Ohms
Transmitter
- TX-range
- 8-10 m
3.5-4 / 7-7.5 / 14-14.5 / 21-21.5 / 28.5-29 MHz - Modulations
- AM CW USB LSB
- RF-output
- 100 W (240 W input)
Connections
- Antenna
- -
- Impedance
- 50-100Ω
- Other
- -
Electrical
- Power requirements
- External PSU
- Current drain RX
- ?
- TX
- ?
Physical
- Dimensions (w×h×d)
- ?
- Weight
- 8.00 kg (17.7 lbs)
- Form factor
- Base Station
- Manufactured
- Between 197x and 198x
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 6407
- MPN
- TEMPO-ONE
Manuals, diagrams and brochures
- Tempo 1 Instruction Manual PDF - 3.41 MB, submitted by Michael Ince
- Tempo One Schematic diagram PDF - 505.2 kB, submitted by Michael Ince
