The Atlas 215 is a 15-160 m transceiver. RF output is 100 W. Power requirements are 13.8V DC. Current drain is 300-500 mA in receive and max 16 A in transmit. Dimensions are 90 × 250 × 250 mm.
General characteristics
- HAM bands
- 160m 80m 40m 20m 15m
- Frequency stability
- ?
- Tuning steps
- Continuous
- Memories
- None
Receiver
- RX-range
- 15-160 m
- Modulations
- CW SSB
- Sensitivity
- ?
- Selectivity
- ?
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 15-160 m
- Modulations
- CW SSB
- RF-output
- 100 W
Connections
- Antenna
- SO-239
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 13.8V DC
- Current drain RX
- 300-500 mA
- TX
- Max 16 A
Physical
- Dimensions (w×h×d)
- 250 × 90 × 250 mm (9.84 × 3.54 × 9.84 in)
- Weight
- ?
- Form factor
- Base Station
- Manufactured
- Between 197x and 19xx
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 6425
- MPN
- ATLAS-000215
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Atlas 215. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
These estimates are based on the following prices:
