A truly plug-n-play integrated networked receiver combined with a host computer and more, all in one box. When connected to the internet via ethernet or WiFi, it can be accessed from anywhere. It can also be used locally via USB.
14-bit ADC. Twelve high-selectivity front end filters. Selectable FM, MW and DAB notch filters. Three software selectable antenna ports. Up to 10 MHz of spectrum can be monitored and recorded. External reference clock input (MCX jack). 4.7 V DC bias tee output on port B. SDRUno and SDRconnect software included. Other popular SDR packages are also supported.
General characteristics
- HAM bands
- ?
- Frequency stability
- ±0.5 p.p.m. @ -30 to +85°C (-22 to +185°F)
- Tuning steps
- Software dependent
- Memories
- ?
Receiver
- RX-range
- 0.001-2000 MHz
- Modulations
- Multiple (Software defined)
- Sensitivity
- ?
- Selectivity
- ?
- Filters
- ?
- Receiver system
- SDR
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Connections
- Antenna
- BNC + SMA
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 5 V DC (USB-C
- Current drain RX
- < 600 mA
- TX
- ?
Physical
- Dimensions (w×h×d)
- 200 × 40 × 105 mm (7.87 × 1.57 × 4.13 in)
- Weight
- 800 gr (1.8 lbs)
- Form factor
- Headless
- Manufactured
- Between 2024 and 20xx in Great Britain
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 6632
- MPN
- SDRPLAY-NRSP-ST
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used SDRplay nRSP-ST. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic data, today's second-hand price of the SDRplay nRSP-ST is around:
- EUR 554.00
These estimates are based on the following prices:
