General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
144-146 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 MHz
Modulations
FM
RF-output
High: 2.5-6 W (depending on voltage), Low: ? W

Connections

Antenna
BNC
Impedance
50 Ω
Other
-

Electrical

Power requirements
?V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
?
Weight
?
Form factor
Handheld
Manufactured
Between 199x and 199x

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
2234
MPN
ALINCO-DJ-000120E

Manuals, diagrams and brochures

Alinco DJ-120 Instruction manual PDF - Unknown size, submitted by RigReference
Alinco DJ-120T/E Service Manual PDF - 1.78 MB, submitted by Gerd
