Alinco DR-110T

General characteristics

HAM bands

2m

Frequency stability

?

Tuning steps

5 / 10 / 12.5 / 15 / 20 / 25 kHz

Memories

14 channels in 1 bank(s)

Receiver

RX-range

144-148 MHz

Modulations

FM

Sensitivity

-15 dB micro or less (12 dB SINAD)

Selectivity

6 kHz @ -6 dB / 15 kHz @ -60 dB

Filters

?

Receiver system

Double conversion superheterodyne

IF-frequencies

10.7 MHz / 455 kHz

Image rejection

?

Audio output

1.5 W (8 ohm load) @ 5% distortion

Transmitter

TX-range

144-148 MHz

Modulations

FM

RF-output

5 / 45 W

Connections

Antenna

SO-239

Impedance

50Ω

Other

-

Electrical

Power requirements

13.8 V DC

Current drain RX

0.5 A

TX

9.5 A max

Physical

Dimensions (w×h×d)

140 × 40 × 149 mm (5.51 × 1.57 × 5.87 in)

Weight

1.10 kg (2.4 lbs)

Form factor

Mobile

Manufactured

Between 199x and 199x

Other features

Usage

Amateur / Ham radio operators

Features + options

-

Accessories

-

RigReference ID

2307

MPN

ALINCO-DR-000110T

Manuals, diagrams and brochures

Alinco DR-110/112/410 Instruction manual PDF - Unknown size, submitted by RigReference
