General characteristics
- HAM bands
- 2m
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- 20 channels in 1 bank(s)
Receiver
- RX-range
- 144-146 MHz (Europe)
144-148 MHz (USA) (140-152 MHz after modification) - Modulations
- FM
- Sensitivity
- 0.2 µV (12 dB SINAD)
- Selectivity
- 12 kHz (-6 dB), 30 kHz (-60 dB)
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 144-146 MHz (Europe)
144-148 MHz (USA) (140-152 MHz after modification) - Modulations
- FM
- RF-output
- High: 25 W, Low: 5 W
Connections
- Antenna
- SO-239
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- 13.8V DC
- Current drain RX
- Max 300 mA
- TX
- Max 6 A
Physical
- Dimensions (w×h×d)
- 140 × 50 × 182 mm (5.51 × 1.97 × 7.17 in)
- Weight
- 1.40 kg (3.1 lbs)
- Form factor
- Mobile
- Manufactured
- Between 19xx and 19xx in Japan
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- CTCSS
- Accessories
- -
- RigReference ID
- 2426
- MPN
- AZDEN-PCS-005000
Manuals, diagrams and brochures
-
No documents available for this particular model.
