General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
146-148 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
XTAL-synthesis
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
146-148 MHz
Modulations
FM
RF-output
25 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
400 mA
TX
6 A max

Physical

Dimensions (w×h×d)
?
Weight
?
Form factor
Mobile
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
2489
MPN
CLEGG-FM-000027B

Manuals, diagrams and brochures

Clegg FM-27B QST ad (Jan 1973) PDF - Unknown size, submitted by RigReference
Clegg FM-27B Owner's Manual PDF - Unknown size, submitted by RigReference
Clegg FM-27B Owner's Manual Supplement PDF - Unknown size, submitted by RigReference
Clegg FM-27 Series Some Engineering Drawings PDF - Unknown size, submitted by RigReference
Clegg FM-27 x-tal Extension Parts List PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Rating Title Submitted
Fun Old-Tyme Radio once you figure it out! 10 years ago by JohnnyElectron

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Clegg FM-27B. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Clegg FM-27B is around:

  • USD 24.00 ~ USD 1.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2010 USD 55.00 Used / Good JohnnyElectron
2010 USD 61.00 Used / Good eBay
2010 USD 5.00 Used / Poor eBay
