General characteristics

HAM bands
80m  40m  20m  15m  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
10-80 m
Modulations
AM   CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Connections

Antenna
-
Impedance
50 Ω
Other
-

Electrical

Power requirements
Mains
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
375 × 197 × 317 mm (14.76 × 7.76 × 12.48 in)
Weight
9.10 kg (20.1 lbs)
Form factor
Base Station
Manufactured
Between 1963 and 1975 in USA

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
2518
MPN
COLLINS-000075S-3B

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Collins 75S-3B. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Collins 75S-3B is around:

  • USD 136.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2006 USD 850.00 Used / Good K9XT
