Collins HF-8054A

Desktop Shortwave receiver

Specs Manuals (0) Reviews (0) Prices (0) Compare

The Collins HF-8054A is a desktop shortwave receiver covering 0.25-30 MHz with 0.01 kHz tuning steps. It requires mains power and has a maximum current drain of 80 W in receive mode. Dimensions are 222 × 483 × 520 mm and it weighs 20 kg. The HF-8054A features remote control.

General characteristics

HAM bands: ?
Frequency stability: ?
Tuning steps: 0.01 kHz
Memories: ?

Receiver

RX-range: 0.25-30 MHz
Modulations: AM FM CW SSB ISB
Sensitivity: ?
Selectivity: ?
Filters: ?
Receiver system: ?
IF-frequencies: ?
Image rejection: ?
Audio output: ?

Connections

Antenna: -
Impedance: 50 Ω
Other: -

Electrical

Power requirements: Mains
Current drain RX: Max 80 W
TX: -

Physical

Dimensions (w×h×d): 483 × 222 × 520 mm (19.02 × 8.74 × 20.47 in)
Weight: 20.00 kg (44.1 lbs)
Form factor: Base Station
Manufactured: Between 1982 and 1986 in Canada

Other features

Usage: Amateur / Ham radio operators
Features + options: Remote control.
Accessories: -
RigReference ID: 2524
MPN: COLLINS-HF-008054A

We do our best to be accurate, but if you've spotted something wrong or incomplete, please let us know!

Manuals, diagrams and brochures

: No documents available for this particular model.

: Upload relevant documents

Reviews

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Collins HF-8054A. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on similar Receiver equipment, the estimated value of the Collins HF-8054A is around:

USD 265 ~ USD 492

This estimate is based on similar equipment and may not reflect the exact value of this model.

These estimates are based on the following prices:
