The digital readout of the R-77 may be used as a 150 MHz counter. Tunable IF Notch.
General characteristics
- HAM bands
- ?
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- ?
Receiver
- RX-range
- 0.01-30 MHz
- Modulations
- AM AM-sync CW SSB
- Sensitivity
- ?
- Selectivity
- ?
- Filters
- 0.3 / 0.5 / 1.8 / 2.3 / 4 kHz
- Receiver system
- Triple conversion superheterodyne
- IF-frequencies
- 1st: 50MHz
2nd: 5645kHz
3rd: 4805kHz - Image rejection
- ?
- Audio output
- ?
Connections
- Antenna
- -
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- 13.8V DC or mains
- Current drain RX
- Max 2 A
- TX
- -
Physical
- Dimensions (w×h×d)
- 346 × 117 × 318 mm (13.62 × 4.61 × 12.52 in)
- Weight
- ?
- Form factor
- Base Station
- Manufactured
- Between 19xx and 19xx
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 2582
- MPN
- DRAKE-R-000077
