General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
?
Memories
6 channels in 1 bank(s)

Receiver

RX-range
144-148 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
XTAL
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-148 MHz
Modulations
FM
RF-output
1 W

Connections

Antenna
Built-in sweep
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
45 mA
TX
650 mA

Physical

Dimensions (w×h×d)
135 × 58 × 181 mm (5.31 × 2.28 × 7.13 in)
Weight
1.70 kg (3.8 lbs) 10 × NiCd and mic included
Form factor
Handheld
Manufactured
Between 197x and 197x

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
2599
MPN
DRAKE-TR-000022

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Drake TR-22. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic price data, today's estimated value of the Drake TR-22 in Good condition is around:

  • USD 58 ~ USD 75

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2010 USD 58.00 Used / Good eBay
1974 USD 75.00 Used / Good ZedderBRL
