Drake TR-33C

Mobile VHF Transceiver

Specs Manuals (0) Reviews (0) Prices (0) Compare

The Drake TR-33C is a mobile VHF transceiver. It covers 146-148 MHz for both receive and transmit. The RF output is 1.5 W. It features 1 memory bank with 12 channels. Power requirements are 13.8V DC. Dimensions are 58 × 138 × 216 mm. Current drain in receive is 30-75 mA and max 445 mA in transmit.

General characteristics

HAM bands: 2m
Frequency stability: ?
Tuning steps: ?
Memories: 12 channels in 1 bank(s)

Receiver

RX-range: 146-148 MHz
Modulations: FM
Sensitivity: ?
Selectivity: ?
Filters: ?
Receiver system: XTAL
IF-frequencies: ?
Image rejection: ?
Audio output: ?

Transmitter

TX-range: 146-148 MHz
Modulations: FM
RF-output: 1.5 W

Connections

Antenna: Built-in telescopic
Impedance: 50Ω
Other: -

Electrical

Power requirements: 13.8V DC
Current drain RX: 30-75 mA
TX: Max 445 mA

Physical

Dimensions (w×h×d): 138 × 58 × 216 mm (5.43 × 2.28 × 8.50 in)
Weight: 2.00 kg (4.4 lbs)
Form factor: Mobile
Manufactured: Between 19xx and 19xx

Other features

Usage: Amateur / Ham radio operators
Features + options: -
Accessories: -
RigReference ID: 2602
MPN: DRAKE-TR-000033C

We do our best to be accurate, but if you've spotted something wrong or incomplete, please let us know!

Manuals, diagrams and brochures

: No documents available for this particular model.

: Upload relevant documents

Reviews

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Drake TR-33C. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on similar Transceiver equipment, the estimated value of the Drake TR-33C is around:

USD 210 ~ USD 390

This estimate is based on similar equipment and may not reflect the exact value of this model.

These estimates are based on the following prices:

Year	Historic price	Condition	Submitted by
