The Drake UV-3E is a VHF/UHF transceiver covering 144-146 / 430-440 MHz for both receive and transmit. It has a tuning step of 5 kHz and an RF output of High: 35/10 W, Low: 3.5/1 W. The radio requires 13.8 V DC power and draws 1.1 A in receive mode and 2.5-6.5 A in transmit mode. Dimensions are 90 × 210 × 300 mm.
General characteristics
- HAM bands
- 2m 70cm
- Frequency stability
- ?
- Tuning steps
- 5 kHz
- Memories
- ?
Receiver
- RX-range
- 144-146 / 430-440 MHz
- Modulations
- FM
- Sensitivity
- 144 MHz: 0.5µV
440 MHz: 0.18µV - Selectivity
- ?
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 144-146 / 430-440 MHz
- Modulations
- FM
- RF-output
- High: 35/10 W, Low: 3.5/1 W
Connections
- Antenna
- SO-239
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 13.8 V DC
- Current drain RX
- 1.1 A
- TX
- 2.5-6.5 A
Physical
- Dimensions (w×h×d)
- 210 × 90 × 300 mm (8.27 × 3.54 × 11.81 in)
- Weight
- 5.00 kg (11.0 lbs)
- Form factor
- Base Station
- Manufactured
- Between 1978 and 198x
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 2611
- MPN
- DRAKE-UV-000003E
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Drake UV-3E. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on similar Transceiver equipment, the estimated value of the Drake UV-3E is around:
- USD 215 ~ USD 400
This estimate is based on similar equipment and may not reflect the exact value of this model.
