Also available with XM Satellite radio option as the Etón E1 XM.

General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m  2000m
Frequency stability
?
Tuning steps
9 / 10 kHz
Memories
1700 channels in 1 bank(s)

Receiver

RX-range
0.1-30 / 87-108 MHz
Modulations
AM   AM-sync   W-FM Stereo   CW   SSB
Sensitivity
?
Selectivity
7.0 / 4.0 / 2.5 kHz
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Connections

Antenna
Built-in ferrite bar + Built-in telescopic + KOK1 (Motorola/DIN41585)
Impedance
50Ω
Other
Line in / out
Ext. speaker
Headphones

Electrical

Power requirements
9 V DC (4 × R20 / D cells)
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
333 × 180 × 58 mm (13.11 × 7.09 × 2.28 in)
Weight
1.90 kg (4.2 lbs)
Form factor
Portable
Manufactured
Between 200x and 200x

Other features

Usage
Amateur / Ham radio operators
Features + options
Dual clocks and timers. PBT 320*240 pixel 5.7", 240 × 320 pixel LCD
Accessories
-
RigReference ID
2654
MPN
ETÓN-E000001

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Rating Title Submitted
Top class performance 9 years ago by magnus

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Etón E1. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Etón E1 is around:

  • EUR 120.00
  • USD 60.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2007 USD 300.00 New / Mint NT7J
2007 EUR 600.00 New / Mint magnus
