The Hallicrafters S-38D is a HF Receiver covering 0.54-32 MHz in four bands. It features continuous tuning, L/C filters and a receiver system with 5 tubes, single conversion and an oscillating IF at 455 kHz. The audio output is 1 W. The receiver requires Mains (AC or DC) power and draws 30 W @ 110 V AC. Dimensions are 190 × 330 × 225 mm.
General characteristics
- HAM bands
- ?
- Frequency stability
- Marginal
- Tuning steps
- Continuous tuning
- Memories
- ?
Receiver
- RX-range
- 0.54-32 MHz in four bands
- Modulations
- AM CW
- Sensitivity
- Unpublished
- Selectivity
- Unpublished
- Filters
- L/C
- Receiver system
- 5 tubes, Single conversion, oscillating IF
- IF-frequencies
- 455 kHz
- Image rejection
- ?
- Audio output
- 1 W
Connections
- Antenna
- -
- Impedance
- 52-600Ω
- Other
- -
Electrical
- Power requirements
- Mains (AC or DC)
- Current drain RX
- 30 W @ 110 V AC
- TX
- -
Physical
- Dimensions (w×h×d)
- 330 × 190 × 225 mm (12.99 × 7.48 × 8.86 in)
- Weight
- 5.00 kg (11.0 lbs)
- Form factor
- Base Station
- Manufactured
- Between 195x and 195x in USA
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 2773
- MPN
- HALLICRAFTERS-S-000038D
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Hallicrafters S-38D. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic data, today's second-hand price of the Hallicrafters S-38D is around:
- USD 3.00 ~ USD 2.00
These estimates are based on the following prices:
