The ICOM IC-1200 is a handheld UHF transceiver. It covers 1240-1300 MHz for both receive and transmit. The IC-1200 has selectable tuning steps of 12.5 or 25 kHz. RF output power is selectable between High: 10 W and Lo 1 W. It features 1 memory bank with 21 channels. Power requirements are 13.8V DC. The current drain in receive mode is 600-900 mA, and the maximum current drain in transmit mode is 5.5 A. The IC-1200 weighs 1.5 kg.
General characteristics
- HAM bands
- ?
- Frequency stability
- ?
- Tuning steps
- 12.5 / 25 kHz
- Memories
- 21 channels in 1 bank(s)
Receiver
- RX-range
- 1240-1300 MHz
- Modulations
- FM
- Sensitivity
- ?
- Selectivity
- ?
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 1240-1300 MHz
- Modulations
- FM
- RF-output
- High: 10 W, Lo 1 W
Connections
- Antenna
- N-type
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- 13.8V DC
- Current drain RX
- 600-900 mA
- TX
- Max 5.5 A
Physical
- Dimensions (w×h×d)
- ?
- Weight
- 1.50 kg (3.3 lbs)
- Form factor
- Handheld
- Manufactured
- Between 1987 and 19xx in Japan
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 2965
- MPN
- ICOM-IC-001200
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-1200. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic price data, today's estimated value of the ICOM IC-1200 in Good condition is around:
- AUD 506
These estimates are based on the following prices:
