General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
144-146 MHz
Modulations
CW   USB   LSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 MHz
Modulations
CW   USB   LSB
RF-output
3 W

Connections

Antenna
Built-in sweep
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
90-250 mA
TX
Max 750 mA

Physical

Dimensions (w×h×d)
61 × 183 × 162 mm (2.40 × 7.20 × 6.38 in)
Weight
2.00 kg (4.4 lbs) incl. batteries
Form factor
Mobile
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
VXO
Accessories
-
RigReference ID
2978
MPN
ICOM-IC-000202S

Manuals, diagrams and brochures

ICOM IC-202 Schematic Diagram-3.gif GIF - Unknown size, submitted by RigReference
ICOM IC-202 Schematic Diagram-2.gif GIF - Unknown size, submitted by RigReference
ICOM IC-202 Schematic Diagram-1.gif GIF - Unknown size, submitted by RigReference
ICOM IC-202 Schematic Diagram-4.gif GIF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-202S. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-202S is around:

  • GBP 108.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2015 GBP 120.00 Used / Good G6UDX
