General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
10 kHz
Memories
?

Receiver

RX-range
220-225 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
220-225 MHz
Modulations
FM
RF-output
High: 1.5 W, Low: 150 mW

Connections

Antenna
BNC
Impedance
50 Ω
Other
-

Electrical

Power requirements
6-10.8V DC
Current drain RX
?
TX
Max 550 mA

Physical

Dimensions (w×h×d)
65 × 117 × 35 mm (2.56 × 4.61 × 1.38 in) without battery
Weight
?
Form factor
Unknown
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
3085
MPN
ICOM-IC-000003AT

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-3AT. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-3AT is around:

  • USD 95.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 USD 100.00 Used / Good Paul Terry Walhus
