General characteristics
- HAM bands
- 70cm
- Frequency stability
- ?
- Tuning steps
- 5 / 25 kHz
- Memories
- 5 channels in 1 bank(s)
Receiver
- RX-range
- 430-440 MHz
- Modulations
- FM
- Sensitivity
- <0.3 µV (12 dB SINAD)
- Selectivity
- 15 kHz (-6 dB), 30 kHz (-60 dB)
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- >60 dB
- Audio output
- ?
Transmitter
- TX-range
- 430-440 MHz
- Modulations
- FM
- RF-output
- High: 10 W, Low: 1 W
Connections
- Antenna
- N-type
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- 13.8V DC
- Current drain RX
- 500-700 mA
- TX
- 1.7-3.5 A
Physical
- Dimensions (w×h×d)
- 140 × 50 × 177 mm (5.51 × 1.97 × 6.97 in)
- Weight
- 1.50 kg (3.3 lbs)
- Form factor
- Unknown
- Manufactured
- Between 1983 and 19xx in Japan
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 3095
- MPN
- ICOM-IC-000045E
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-45E. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
These estimates are based on the following prices:
