General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
5 / 25 kHz

Receiver

RX-range
430-440 MHz
Modulations
FM
Sensitivity
<0.3 µV (12 dB SINAD)
Selectivity
15 kHz (-6 dB), 30 kHz (-60 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
>60 dB
Audio output
?

Transmitter

TX-range
430-440 MHz
Modulations
FM
RF-Output
High: 10 W, Low: 1 W

Connections

Antenna
N-type
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
500-700 mA
TX
1.7-3.5 A

Physical

Manufactured
Between 1983 and 19xx in Japan
Dimensions (w×h×d)
140 × 50 × 177 mm (5.51 × 1.97 × 6.97 in)
Weight
1.50 kg (3.3 lbs)
Form factor
Unknown

Other features

Memories
5 channels in 1 bank(s)
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?
MPN
ICOM-IC-000045E

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-45E. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

These estimates are based on the following prices: (see all 0 prices)
