Frequency range

RX-range
430-440 MHz
TX-range
430-440 MHz
HAM bands
70cm
Stability
?
Tuning steps
FM: 1 / 5 / 25 kHz, SSB/CW: 0.1 kHz
Filters
?

Receiver

Modulations
FM   CW   SSB
Sensitivity
?
Selectivity
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 39380 kHz
2nd: 1075 kHz
Image rejection
?
Audio output
internal speaker

Transmitter

Modulations
FM   CW   SSB
RF-Output
High: 10 W, Low: 1 W

Connections

Antenna
N-type
Impedance
50 Ω

Electrical

Power requirements
13.8V DC
Current drain RX
?
TX
3.6 A max

Physical

Dimensions (w×h×d)
170 × 64 × 218 mm (6.69 × 2.52 × 8.58 in)
Weight
2.60 kg (5.7 lbs)
Form factor
Mobile
Manufactured
Between 1982 and 19xx
MPN
ICOM-IC-000490E

Other features

Memories
4 channels in 1 bank(s)
Usage
Amateur / Ham radio operators
Features + options
Dual VFO's. Scanning
