General characteristics

HAM bands
160m  80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
0.5-30 MHz
Modulations
AM   FM   CW   SSB
Sensitivity
AM: <2 µV (10 dB S/N)
FM: <0.5 µV (12 dB SINAD)
SSB/CW: <0.15 µV (10 dB S/N)
Selectivity
AM: >6 kHz (-6 dB), <20 kHz (-60 dB)
FM: >15 kHz (-6 dB), <30 kHz (-60 dB)
SSB/CW: >2.3 kHz (-6 dB), <4 kHz (-60 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-160 m + WARC
Modulations
AM   FM   CW   SSB
RF-output
100 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
1.2-1.5 A
TX
Max 20 A

Physical

Dimensions (w×h×d)
241 × 94 × 239 mm (9.49 × 3.70 × 9.41 in)
Weight
4.70 kg (10.4 lbs)
Form factor
Base Station
Manufactured
Between 1988 and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
3139
MPN
ICOM-IC-000725

Manuals, diagrams and brochures

Icom IC-725 Service Manual PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Rating Title Submitted
All around solid HF rig and excellent starter 10 years ago by K7IN

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-725. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-725 is around:

  • EUR 270.00
  • GBP 245.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2017 GBP 250.00 Used / Good BandRunner
2015 EUR 300.00 Used / Good lz1uh
