Tuned frequency can be announced in morse code.

General characteristics

HAM bands
6m  2m  70cm
Frequency stability
?
Tuning steps
?
Memories
555 channels in 18 bank(s)

Receiver

RX-range
0.495-999.990 MHz (Cellular blocked)
Modulations
AM   FM   W-FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
50-54 / 144-148 / 440-450 MHz
Modulations
FM
RF-output
High: 5/5/5 W, Low: 0.5/0.5/0.5 W

Connections

Antenna
SMA
Impedance
50 Ω
Other
-

Electrical

Power requirements
5.5-11.5V DC
Current drain RX
65-220 mA
TX
Max 2 A

Physical

Dimensions (w×h×d)
58 × 87 × 29 mm (2.28 × 3.43 × 1.14 in)
Weight
240 gr (8.5 oz) with BP-217 and antenna
Form factor
Handheld
Manufactured
Between 2002 and 200x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
DTMF and CTCSS. RIT +/- 5 KHz. 10 dB attenuator. PC-programmable. Alpha tags.
Accessories
-
RigReference ID
3251
MPN
ICOM-IC-T000090

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-T90. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-T90 is around:

  • USD 99.00 ~ USD 213.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2016 USD 224.00 Used / Good Brian
2010 USD 249.95 New / Good universal-radio
