D-Star concept. TCP/IP, E-mail, video & picture capable. Via a 10BASE-T connector, it can be interfaced with the internet.
General characteristics
- HAM bands
- ?
- Frequency stability
- ?
- Tuning steps
- 5 / 6.25 / 10 / 12.5 / 20 / 25 / 50 / 100 kHz
- Memories
- 100 channels in 1 bank(s)
Receiver
- RX-range
- 1240-1300 MHz
- Modulations
- FM DV
- Sensitivity
- FM: 0.18 µV (12 dB SINAD)
4.8 kbps voice: 0.35 µV (BER 1x10-2)
128 kbps data: 1.58 µV (BER 1x10-2) - Selectivity
- FM: 12 kHz (-6 dB), 30 kHz (-60 dB)
GMSK 4.8 kbps: 6 kHz (-6 dB)
GMSK 128 kbps: 140 kHz (-6 dB) - Filters
- ?
- Receiver system
- ? conversion superheterodyne
- IF-frequencies
- ?
- Image rejection
- 50 dB
- Audio output
- ?
Transmitter
- TX-range
- 1240-1300 MHz
- Modulations
- FM DV
- RF-output
- High: 10 W, Low: 1 W
Connections
- Antenna
- N-type
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- 13.8V DC +/-15%
- Current drain RX
- Max 1.5 A
- TX
- Max 7 A
Physical
- Dimensions (w×h×d)
- 150 × 50 × 50 mm (5.91 × 1.97 × 1.97 in) Transceiver: 141×40×166 mm
- Weight
- 1.40 kg (3.1 lbs) Panel + Transceiver
- Form factor
- Mobile
- Manufactured
- Between 200x and 200x in Japan
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 3273
- MPN
- ICOM-ID-000001
Manuals, diagrams and brochures
- ICOM ID-1 Instruction Manual.pdf PDF - Unknown size, submitted by RigReference
- ICOM ID-1 Instruction Manual (addendum-12-04).pdf PDF - Unknown size, submitted by RigReference
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM ID-1. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic data, today's second-hand price of the ICOM ID-1 is around:
- EUR 168.00 ~ EUR 284.00
These estimates are based on the following prices:
