ICOM ID-1 Mobile UHF Transceiver

 (0.0/5)  Add a story   View all stories (0)   Add to my shack



Login or Register to upload images

D-Star concept. TCP/IP, E-mail, video & picture capable. Via a 10BASE-T connector, it can be interfaced with the internet.

Frequency range

RX-range
1240-1300 MHz
TX-range
1240-1300 MHz
HAM bands
-
Stability
-
Tuning steps
5 / 6.25 / 10 / 12.5 / 20 / 25 / 50 / 100 kHz
Filters
-

Receiver

Modulations
FM   DV
Sensitivity
FM: 0.18 µV (12 dB SINAD)
4.8 kbps voice: 0.35 µV (BER 1x10-2)
128 kbps data: 1.58 µV (BER 1x10-2)
Selectivity
FM: 12 kHz (-6 dB), 30 kHz (-60 dB)
GMSK 4.8 kbps: 6 kHz (-6 dB)
GMSK 128 kbps: 140 kHz (-6 dB)
Receiver system
? conversion superheterodyne
IF-frequencies
-
Image rejection
50 dB
Audio output
-

Transmitter

Modulations
FM   DV
RF-Output
High: 10 W, Low: 1 W

Connections

Antenna
N-type
Impedance
50 Ω

Electrical

Power requirements
13.8V DC +/-15%
Current drain RX
Max 1.5 A
TX
Max 7 A

Physical

Dimensions (w×h×d)
150 × 50 × 50 mm (5.91 × 1.97 × 1.97 in) Transceiver: 141×40×166 mm
Weight
1.40 kg (3.1 lbs) Panel + Transceiver
Form factor
Mobile
Manufactured
Between 200x and 200x in Japan
MPN

Other features

Memories
100 channels in 1 bank(s)
Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-

Manuals, diagrams and brochures

ICOM ID-1 Instruction Manual.pdf submitted by RigReference
ICOM ID-1 Instruction Manual (addendum-12-04).pdf submitted by RigReference

Upload relevant documents

Show other documents.

Stories & reviews

Do you know this rig? Tell us something about it!

What is it worth?

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the current value of the ICOM ID-1. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's value of the ICOM ID-1 might be around:

  • EUR 738.00
Price Condition Year User
EUR 1049.00 New / Good 2010 thiecom.de
EUR 899.00 New / Mint 2013 thiecom.de
