The Japan Radio Company NRD-505 was JRCs first non-commercial shortwave receiver geared towards the radio amateur and serious shortwave listener. The NRD-505 tunes 100 kHz to 30 MHz in thirty 1 MHz bands, selected by a large MHz knob. Modes of reception include: RTTY, AM. LSB, USB and CW. This dual conversion superheterodyne circuit provides 0.5 µV 1.6-30 MHz SSB/CW S+N/N=10dB. Digital and analog frequency display is featured. The NRD-505 has an analog S-Meter, RIT, Noise Blanker and attenuator. Supplied filters for AM Wide (4.0 kHz), AM Narrow/SSB/RTTY (2.0 kHz) and optional CW (0.5 kHz). This receiver has modular construction. The rear panel has an SO-239 antenna input jack. There are RCA jacks for Line, Speaker and IF output. There is also a connection for the the matching NSD-505 transmitter. This radio does not have an internal speaker.
General characteristics
- HAM bands
- ?
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- ?
Receiver
- RX-range
- 0.1-30 MHz
- Modulations
- AM CW SSB RTTY
- Sensitivity
- SSB/CW: 0.5 µV (10 dB S+N/N)
- Selectivity
- 6 > 6 kHz
2.2 > 2.4 kHz
0.5 > optional - Filters
- ?
- Receiver system
- Double conversion superheterodyne
- IF-frequencies
- 1st: 70.455 MHz
2nd: 455 kHz - Image rejection
- 1.6-30 MHz: >70 dB
- Audio output
- 1 W @ 4 ohms
Connections
- Antenna
- -
- Impedance
- 50 / 75 Ω
- Other
- -
Electrical
- Power requirements
- Mains, 110/115/220/230 VAC, 50/60 Hz
- Current drain RX
- ?
- TX
- -
Physical
- Dimensions (w×h×d)
- 340 × 140 × 300 mm (13.39 × 5.51 × 11.81 in)
- Weight
- 10.00 kg (22.1 lbs)
- Form factor
- Base Station
- Manufactured
- Between 1977 and 1979
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- RIT, NB
- Accessories
- -
- RigReference ID
- 3295
- MPN
- JRC-NRD-000505
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used JRC NRD-505. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on similar Receiver equipment, the estimated value of the JRC NRD-505 is around:
- USD 265 ~ USD 492
This estimate is based on similar equipment and may not reflect the exact value of this model.
