The KDK FM-2025 is a mobile VHF transceiver. It covers 143.000-148.995 MHz (Asia) or 144.000-148.995 MHz (Europe) for both receive and transmit. Tuning steps are selectable between 5 or 12.5 kHz depending on region. The receiver system is a double superheterodyne with IF frequencies of 1st: 10.7 MHz and 2nd: 455 kHz. Image rejection is ≥ 70 dB. RF output power is selectable between High: 25 W, Low: 3 W. Audio output is ≥ 1.5 W @ 10% THD into 8 Ohms. It has 1 memory bank with 10 channels. Power requirements are 13.8V DC. Dimensions are 60 × 180 × 195 mm and it weighs 2.2 kg.
General characteristics
- HAM bands
- 2m
- Frequency stability
- ?
- Tuning steps
- 5 or 12.5 kHz depending on region
- Memories
- 10 channels in 1 bank(s)
Receiver
- RX-range
- 143.000-148.995 MHz (Asia)
144.000-148.995 MHz (Europe) - Modulations
- FM
- Sensitivity
- S/N ≤ 35 dB: 1uv
S/N ≤ 20 dB: 0.35 µV
SINAD ≤ 10%: 0.5 µV - Selectivity
- ± 6 kHz at -6 dB
± 16 kHz at -60 dB - Filters
- ?
- Receiver system
- Double superheterodyne
- IF-frequencies
- 1st: 10.7 MHz
2nd: 455 kHz - Image rejection
- ≥ 70 dB
- Audio output
- ≥ 1.5 W @ 10% THD into 8 Ohms
Transmitter
- TX-range
- 143.000-148.995 MHz (Asia)
144.000-148.995 MHz (Europe) - Modulations
- FM
- RF-output
- High: 25 W, Low: 3 W
Connections
- Antenna
- -
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- 13.8V DC
- Current drain RX
- ?
- TX
- ?
Physical
- Dimensions (w×h×d)
- 180 × 60 × 195 mm (7.09 × 2.36 × 7.68 in)
- Weight
- 2.20 kg (4.9 lbs)
- Form factor
- Mobile
- Manufactured
- Between 1980 and 19xx
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 3318
- MPN
- KDK-FM-002025
Manuals, diagrams and brochures
- KDK Fm2025 PDF - 3.86 MB, submitted by Mike
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used KDK FM-2025. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic price data, today's estimated value of the KDK FM-2025 in Good condition is around:
- USD 50 ~ USD 225
- AUD 118
These estimates are based on the following prices:
