General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
0.2-30 MHz
Modulations
AM   CW   SSB
Sensitivity
AM (10 dB S+N/N)
0.2-2 MHz: 20 µV
2-30 MHz: 2 µV
SSB (10 dB S+N/N)
0.2-2 MHz: 0.2-2 MHz: 5 µV
2-30 MHz: 0.5 µV
Selectivity
AM Wide: 12 kHz (-6 dB), 25 kHz (-50 dB)
AM Narrow: 6 kHz (-6 dB), 18 kHz (-50 dB)
SSB/CW: 2.7 kHz (-6 dB), 5 kHz (-60 dB)
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 48.055 MHz
2nd: 455 KHz
Image rejection
>60 dB
Audio output
?

Connections

Antenna
SO-239
Impedance
50/1000Ω
Other
-

Electrical

Power requirements
Mains (12V DC option, DCK-1)
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
300 × 115 × 218 mm (11.81 × 4.53 × 8.58 in)
Weight
5.50 kg (12.1 lbs)
Form factor
Base Station
Manufactured
Between 1979 and 1985 in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
12hr clock and timer
Accessories
-
RigReference ID
3335
MPN
KENWOOD-R-001000

Manuals, diagrams and brochures

Kenwood R-1000 Schematic Diagram PDF - Unknown size, submitted by RigReference
Kenwood R-1000 Service Manual PDF - Unknown size, submitted by RigReference
Kenwood R-1000 User Manual PDF - Unknown size, submitted by RigReference

Upload relevant documents

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Kenwood R-1000. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Kenwood R-1000 is around:

  • USD 45.00 ~ USD 59.00
  • GBP 137.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2017 GBP 140.00 Used / Mint jbeggs
2013 USD 249.95 Used / Good universal-radio
2010 USD 150.00 Used / Good jimimaxi2
2007 USD 225.00 Used / Good Radio10
1992 USD 350.00 Used / Good rreh917
