4*LR6 battery case option. Built-in ferrite bar antenna for 0.1-7 MHz VOX.

General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
?
Memories
435 channels in 1 bank(s)

Receiver

RX-range
0.1-1300 MHz
Modulations
AM   FM   CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 / 430-440 MHz
Modulations
FM
RF-output
High: 5/5 W, Low: 0.5/0.5 W, El: 50/50 mW

Connections

Antenna
SMA
Impedance
50 Ω
Other
-

Electrical

Power requirements
Internal: 5-7.5V DC External: 12-16V DC
Current drain RX
100-170 mA (no signal)
TX
0.5-2 A

Physical

Dimensions (w×h×d)
58 × 87 × 30 mm (2.28 × 3.43 × 1.18 in) with lithium-ion battery pack
Weight
250 gr (8.8 oz) with lithium-ion battery pack
Form factor
Handheld
Manufactured
Between 2001 and 200x

Other features

Usage
Amateur / Ham radio operators
Features + options
9K6 packet ready. Twin RX
Accessories
-
RigReference ID
3382
MPN
KENWOOD-TH-F000007E

Manuals, diagrams and brochures

Kenwoon TH-F6A/TH-F7E Instruction Manual PDF - 971.1 kB, submitted by DHall

Upload relevant documents

Reviews & stories

Rating Title Submitted
Nice (very) little TRX. Recommended 4 years ago by dg1un

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Kenwood TH-F7E. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Kenwood TH-F7E is around:

  • EUR 105.00 ~ EUR 179.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2013 EUR 250.00 New / Good Berenland
2010 EUR 265.00 New / Good thiecom.de
2003 EUR 369.00 New / Mint dg1un
