Kenwood TM-742E

Mobile VHF/UHF Transceiver

Specs Manuals (1) Reviews (0) Prices (1) Compare

The Kenwood TM-742E is a mobile VHF/UHF transceiver. It covers 144-146 / 430-440 MHz with options for 10 m, 6 m or 23 cm bands. The RF output is High: 50/35 W, Medium: 10/10 W, Low: 5/5 W. It features triple RX and 1 memory bank with 101 channels. Power requirements are 13.8V DC. Dimensions are 50 × 150 × 175 mm.

General characteristics

HAM bands: 6m 2m 70cm
Frequency stability: ?
Tuning steps: ?
Memories: 101 channels in 1 bank(s)

Receiver

RX-range: 144-146 / 430-440 MHz (10 m, 6 m or 23 cm options)
Modulations: FM
Sensitivity: ?
Selectivity: ?
Filters: ?
Receiver system: ?
IF-frequencies: ?
Image rejection: ?
Audio output: ?

Transmitter

TX-range: 144-146 / 430-440 MHz (10 m, 6 m or 23 cm options)
Modulations: FM
RF-output: High: 50/35 W, Medium: 10/10 W, Low: 5/5 W

Connections

Antenna: -
Impedance: 50 Ω
Other: -

Electrical

Power requirements: 13.8V DC
Current drain RX: Max 1.2 A
TX: Max 11.5 A

Physical

Dimensions (w×h×d): 150 × 50 × 175 mm (5.91 × 1.97 × 6.89 in)
Weight: 1.50 kg (3.3 lbs)
Form factor: Mobile
Manufactured: Between 1994 and 19xx

Other features

Usage: Amateur / Ham radio operators
Features + options: Triple RX
Accessories: -
RigReference ID: 3421
MPN: KENWOOD-TM-000742E

We do our best to be accurate, but if you've spotted something wrong or incomplete, please let us know!

Manuals, diagrams and brochures

: Kenwood TM-642 / TM-742 / TM-942 Instruction Manual PDF - Unknown size, submitted by RigReference

: Upload relevant documents

Reviews

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Kenwood TM-742E. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic price data, today's estimated value of the Kenwood TM-742E in Good condition is around:

USD 650

Price History Chart

These estimates are based on the following prices:

Year	Historic price	Condition	Submitted by
2020	USD 650.00	Used / Good	Jim M.
