Kenwood TR-751E

Mobile VHF Transceiver

View all reviews (1) Add a review Add to my shack



Login or Register to upload images

Find Kenwood TR-751E rigs and spare parts on eBay Find the Kenwood TR-751E on Amazon
We receive a small fee when you buy through these links, thank you!

Frequency range

RX-range
144-146 MHz
TX-range
144-146 MHz
HAM bands
?
Stability
?
Tuning steps
?
Filters
?

Receiver

Modulations
All mode
Sensitivity
SSB/CW: Better thatn 0.13 µV (10 dB S+N/N)
FM: Better than 0.2 µV (12 dB SINAD)
Selectivity
SSB/CW: 2.2 kHz (-6 dB), 4.8 kHz (-60 dB)
FM: 12 kHz (-6 dB), 24 kHz (-60 dB)
Receiver system
?
IF-frequencies
?
Image rejection
Better than 60 dB
Audio output
?

Transmitter

Modulations
All mode
RF-Output
High: 25 W, Low: 5 W

Connections

Antenna
SO-239
Impedance
50 Ω

Electrical

Power requirements
11-16V DC
Current drain RX
Max 1 A
TX
Max 6 A

Physical

Dimensions (w×h×d)
180 × 60 × 195 mm (7.09 × 2.36 × 7.68 in)
Weight
2.10 kg (4.6 lbs)
Form factor
Mobile
Manufactured
Between 1986 and 19xx
MPN
KENWOOD-TR-000751E

Other features

Memories
10 channels in 1 bank(s)
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?

Manuals, diagrams and brochures

Kenwood TR-751 Schematic Diagram submitted by RigReference

Upload relevant documents

Show other documents.
Find the Kenwood TR-751E user manuals on eBay #ad

Reviews & stories

good receiver - build quality lets down in places

Kenwood TR-751E, Mobile VHF Transceiver

Very good ears! Hears well, good TX Audio. Pity about the problems with the potentiometers! Cheap Pots let down an otherwise excellent rig from Kenwood. You can't get spares anymore and iI resorted to building a breakout box, replacing the on/off switch, audio gain, RF gain, squelch and R.I.T. functions. This was the only way I found to save this from the parts box. The fact that I bothered should stand as testament to what I think about the performance of this great little box. I will be gutted when it finally dies.

GM4UPN

Written by gm4upn on Nov 29, 2011

Overall

Performance
Build quality
Features
User friendlyness
Value for money
Aquired
Okay condition in 2011
GBP 125.00

What's it worth

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the current value of the Kenwood TR-751E. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's value of the Kenwood TR-751E might be around:

  • USD 124.00
Year Historic price Condition Submitted by
2010 USD 250.00 Used / Fair WD8FM
