Frequency range

RX-range
50-54 MHz
TX-range
50-54 MHz
HAM bands
?
Stability
?
Tuning steps
?
Filters
?

Receiver

Modulations
AM   CW
Sensitivity
?
Selectivity
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

Modulations
AM   CW
RF-Output
1 W

Connections

Antenna
-
Impedance
50 Ω

Electrical

Power requirements
12V DC (8R14 / C batteries)
Current drain RX
50 mA
TX
Max 400 mA

Physical

Dimensions (w×h×d)
165 × 63 × 185 mm (6.50 × 2.48 × 7.28 in)
Weight
1.50 kg (3.3 lbs)
Form factor
Unknown
Manufactured
Between 1976 and 19xx in Japan
MPN
MIZUHO-MK-000610

Other features

Memories
?
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Show other documents.
Find the Mizuho MK-610 user manuals on eBay

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Mizuho MK-610. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Year Historic price Condition Submitted by
