Mizuho MX-14S

Handheld Shortwave Transceiver

View all reviews (1) Add a review Add to my shack



Login or Register to upload images

Frequency range

RX-range
20m (50 kHz per XTAL)
TX-range
20m (50 kHz per XTAL)
HAM bands
?
Stability
?
Tuning steps
?
Filters
?

Receiver

Modulations
CW   SSB
Sensitivity
?
Selectivity
?
Receiver system
VXO. Max 2 XTALS
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

Modulations
CW   SSB
RF-Output
2 W

Connections

Antenna
-
Impedance
50 Ω

Electrical

Power requirements
9.5V DC
Current drain RX
68 mA
TX
Max 600 mA

Physical

Dimensions (w×h×d)
66 × 142 × 39 mm (2.60 × 5.59 × 1.54 in)
Weight
645 gr (1.4 lbs) batteries included
Form factor
Handheld
Manufactured
Between 1987 and 2002 in Japan
MPN
MIZUHO-MX-000014S

Other features

Memories
?
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Show other documents.
Find the Mizuho MX-14S user manuals on eBay

Reviews & stories

Time consuming,

Mizuho MX-14S, Handheld Shortwave Transceiver

What a ingenious bit of kit.I have used it everywhere, made lots of contacts and always welcomed by the big boys with their Kw burners.
5/9 reports and 599 reports from all over the world when the bands are open. My rig came with an amp but never needed to use it. 1Watt will get you anywhere when conditions are there.

Overall

Performance
Build quality
Features
User friendlyness
Value for money
Aquired
Mint condition in 1994
GBP 150.00

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Mizuho MX-14S. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Mizuho MX-14S is around:

  • GBP 4.00
Year Historic price Condition Submitted by
1994 GBP 150.00 Used / Mint keng4ztg
