Frequency range

RX-range
6 m (50 KHz per XTAL)
TX-range
6 m (50 KHz per XTAL)
HAM bands
?
Stability
?
Tuning steps
?
Filters
?

Receiver

Modulations
CW   SSB
Sensitivity
?
Selectivity
?
Receiver system
VXO. Max 2 XTALS
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

Modulations
CW   SSB
RF-Output
250 mW

Connections

Antenna
BNC
Impedance
50 Ω

Electrical

Power requirements
9.5V DC
Current drain RX
40 mA
TX
Max 180 mA

Physical

Dimensions (w×h×d)
66 × 142 × 39 mm (2.60 × 5.59 × 1.54 in)
Weight
645 gr (1.4 lbs) batteries included
Form factor
Unknown
Manufactured
Between 1983 and 19xx in Japan
MPN
MIZUHO-MX-000006Z

Other features

Memories
?
Usage
Amateur / Ham radio operators
Features + options
?
