General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?

Receiver

RX-range
6 m (50 KHz per XTAL)
Modulations
CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
VXO. Max 2 XTALS
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
6 m (50 KHz per XTAL)
Modulations
CW   SSB
RF-Output
250 mW

Connections

Antenna
BNC
Impedance
50 Ω
Other
-

Electrical

Power requirements
9.5V DC
Current drain RX
40 mA
TX
Max 180 mA

Physical

Manufactured
Between 1983 and 19xx in Japan
Dimensions (w×h×d)
66 × 142 × 39 mm (2.60 × 5.59 × 1.54 in)
Weight
645 gr (1.4 lbs) batteries included
Form factor
Unknown

Other features

Memories
?
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?
MPN
MIZUHO-MX-000006Z
