Can hold eight "C" cells for portable operation. This model lacked adequate stability and image rejection. Note that, unlike the DX-300, the switch for Wide/Narrow on the DX-302 is for a true IF filter selection.

General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
0.01-30 MHz
Modulations
AM   CW   USB   LSB
Sensitivity
?
Selectivity
5 / 7 kHz
Filters
?
Receiver system
Triple conversion superheterodyne
IF-frequencies
?
Image rejection
?
Audio output
?

Connections

Antenna
SO-239 + Clamps / screws
Impedance
?
Other
-

Electrical

Power requirements
Mains or 12V DC
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
360 × 165 × 235 mm (14.17 × 6.50 × 9.25 in)
Weight
6.35 kg (14.0 lbs)
Form factor
Base Station
Manufactured
Between 1981 and 1982

Other features

Usage
Amateur / Ham radio operators
Features + options
¼" Head. Jack, S-Meter, Mute Line, ANL, Dial Lamp, Standby, Fine Tuning, Key Input Jack, Attenuator, Antenna Trimmer, Preselector, Dial Lamp Switch, Record Jack, AGC.
Accessories
-
RigReference ID
3828
MPN
RADIOSHACK-/-REALISTIC-DX-000302

Manuals, diagrams and brochures

Realistic DX-302 Owner's Manual PDF - 13.05 MB, submitted by Gerd
Realistic DX-302 Service Manual PDF - 6.27 MB, submitted by Gerd
Realistic DX-302 Schematic Diagram PDF - 4.56 MB, submitted by Gerd

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used RadioShack / Realistic DX-302. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the RadioShack / Realistic DX-302 is around:

  • AUD 349.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 AUD 350.00 New / Mint Leisa
