Sommerkamp TS-780DX

Mobile 10m Transceiver

Specs Manuals (0) Reviews (0) Prices (0) Compare

10m. amateur transceiver for 10m. DX amateurs, covering frequency range 28.0-28.40, 28.5-28.9, 29.1-29.5 MHz, all modes : SSB (USB+LSB), AM, FM, CW. 170 Watt Signal switchable to 2 Watt, separate RX clarifier and RX/TX Clarifier (VXO), SWR, RF and S -indication, scanner, sensible PA protection circuit. Accessory : remote control microphone with all major functions and digital channel display

General characteristics

HAM bands: 10m
Frequency stability: ?
Tuning steps: 10 kHz
Memories: 120 channels in 1 bank(s)

Receiver

RX-range: 28 MHz
Modulations: AM FM CW USB LSB
Sensitivity: ?
Selectivity: ?
Filters: ?
Receiver system: ?
IF-frequencies: ?
Image rejection: >50 dB
Audio output: Internal speaker

Transmitter

TX-range: 28 MHz
Modulations: AM FM CW USB LSB
RF-output: Hi 100 W, Lo 2W

Connections

Antenna: SO-239
Impedance: 50Ω
Other: -

Electrical

Power requirements: 13.8V DC
Current drain RX: ?
TX: Max 20 A

Physical

Dimensions (w×h×d): ?
Weight: ?
Form factor: Mobile
Manufactured: Between 197x and 197x in Japan

Other features

Usage: Amateur / Ham radio operators
Features + options: -
Accessories: -
RigReference ID: 3996
MPN: SOMMERKAMP-TS-000780DX
