General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
5 / 10 / 12.5 / 20 / 25 / 50 / 100 / 1000 kHz
Memories
33 channels in 1 bank(s)

Receiver

RX-range
144-146 / 430-440 MHz
Modulations
FM
Sensitivity
0.16 µV (12 dB SINAD)
Selectivity
12 kHz (-6 dB), 24 kHz (-60 dB)
Filters
?
Receiver system
2 m/70 cm: Double-conversion superheterodyne
IF-frequencies
1st: 21.8 MHz (2 m), 47.05 MHz (70 cm)
2nd: 455 KHz (2 m/70 cm)
Image rejection
2 m: 65 dB 70 cm: 60 dB
Audio output
?

Transmitter

TX-range
144-146 / 430-440 MHz
Modulations
FM
RF-output
High: 50/40 W, Medium: 5/5 W, Low: 1/1 W

Connections

Antenna
-
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC or mains
Current drain RX
1.3 A
TX
Max 12 A

Physical

Dimensions (w×h×d)
362 × 109 × 365 mm (14.25 × 4.29 × 14.37 in)
Weight
11.50 kg (25.4 lbs)
Form factor
Base Station
Manufactured
Between 1991 and 199x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
Remote control. CTCSS and DTMF options.
Accessories
-
RigReference ID
4073
MPN
STANDARD-C-000050D
