The Yaesu FT-1000MP introduced Enhanced Digital Signal Processing (EDSP) providing an impressive array of noise-reduction and interference rejection filters never before available in the communications industry. Mindful of the critical need to preserve signal-to-noise ratio and IF skirt selectivity throughout the receiver, Yaesu engineers have retained the wide variety of IF filters and high intercept front-end that made the FT-1000D a best seller. Using this RF/IF design as a foundation and the FT-1000MP's EDSP system and Collins Mechanical Filter, the result is a uniquely clean sounding transmitter, with outstanding receiver performance. The Quad conversion receiver covers 100 kHz to 30 MHz. RF output is adjustable to 100 watts [25W AM] in SSB/CW/AM/FM/AFSK modes. The supply voltage is 90~129/180~258 V AC or 13.5 V DC 19 Amps.

General characteristics

HAM bands
160m  80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  10m
Frequency stability
?
Tuning steps
Continuous
Memories
?

Receiver

RX-range
100 kHz - 30 MHz
Modulations
AM   FM   CW   USB   LSB   AFSK   RTTY
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
Quad conversion superheterodyne
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-160 m + WARC
Modulations
AM   FM   CW   USB   LSB   AFSK   RTTY
RF-output
FM/SSB/CW: 100 W, AM: 25 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC or mains
Current drain RX
Max 2.8
TX
Max 19 A

Physical

Dimensions (w×h×d)
410 × 135 × 347 mm (16.14 × 5.31 × 13.66 in)
Weight
15.00 kg (33.1 lbs)
Form factor
Base Station
Manufactured
Between 1996 and 200x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
Twin VFO
Accessories
-
RigReference ID
4227
MPN
YAESU-FT-001000MP

Manuals, diagrams and brochures

Yaesu FT-1000mp Technical Supplement PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Rating Title Submitted
a really good Contest-TRX 8 years ago by do5bfh

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FT-1000MP. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Yaesu FT-1000MP is around:

  • EUR 347.00
  • USD 472.00 ~ USD 654.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 USD 1225.00 Used / Mint eBay
2020 USD 655.00 Used / Fair eBay
2011 EUR 700.00 Used / Okay do5bfh
2010 USD 1186.00 Used / Mint eBay
2010 USD 1425.00 Used / Mint eBay
