External VFO option (FV-101Z)

General characteristics

HAM bands
160m  80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
10-160 m + WARC (Early versions did NOT feature the WARC bands)
Modulations
AM   CW   SSB
Sensitivity
AM: 0.5 µV (10 dB S/N)
SSB/CW: 0.25 µV (10 dB S/N)
Selectivity
2.4 kHz (-6 dB), 4 kHz (-60 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
>60 dB (15-160 m) >50 dB (10 m)
Audio output
?

Transmitter

TX-range
10-160 m + WARC (Early versions did NOT feature the WARC bands)
Modulations
AM   CW   SSB
RF-output
AM: 30 W (DC), SSB/CW: 100 W

Connections

Antenna
SO-239
Impedance
50/75 Ω
Other
-

Electrical

Power requirements
Mains (13.8V DC option)
Current drain RX
5.5 A (1.1 A heater off)
TX
Max 21 A

Physical

Dimensions (w×h×d)
345 × 157 × 326 mm (13.58 × 6.18 × 12.83 in)
Weight
15.00 kg (33.1 lbs)
Form factor
Base Station
Manufactured
Between 1979 and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
4236
MPN
YAESU-FT-000101ZD

Manuals, diagrams and brochures

Yaesu FT-101ZD Manual and Schematic PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FT-101ZD. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Yaesu FT-101ZD is around:

  • EUR 58.00 ~ EUR 141.00
  • USD 56.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2010 EUR 355.88 Used / Good eBay
2006 USD 350.00 Used / Mint ai4wm
2005 EUR 450.00 Used / Mint iz0eyj
1998 EUR 500.00 Used / Good dk7ub
