There is supposedly also a FT-203CP or FT-203R CP version which has a housing made of transparent and impact-resistant plastic.
General characteristics
- HAM bands
- 2m
- Frequency stability
- ?
- Tuning steps
- 5 kHz
- Memories
- ?
Receiver
- RX-range
- 144-146 MHz (Europe and Asia)
144-148 MHz (USA) - Modulations
- FM
- Sensitivity
- 0.25 µV (12 dB SINAD)
1 µV (30 dB S/N) - Selectivity
- ± 6 kHz (- 6 dB)
± 12 kHz (-60 dB) - Filters
- ?
- Receiver system
- Double conversion superheterodyne
- IF-frequencies
- 1st: 10.695 MHz
2nd: 455 kHz - Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 144-146 MHz (Europe and Asia)
144-148 MHz (USA) - Modulations
- FM
- RF-output
- 2.5/0.3 W
Connections
- Antenna
- BNC
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- 5.5-13V DC
- Current drain RX
- 20-100 mA
- TX
- 700 mA
Physical
- Dimensions (w×h×d)
- 65 × 153 × 34 mm (2.56 × 6.02 × 1.34 in)
- Weight
- 450 gr (15.9 oz)
- Form factor
- Handheld
- Manufactured
- Between 198x and 198x
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- PLL with thumbwheels. VOX
- Accessories
- -
- RigReference ID
- 4250
- MPN
- YAESU-FT-000203R
