General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
10 kHz
Memories
4 channels in 1 bank(s)

Receiver

RX-range
Europe: 144-146 MHz
USA: 144-148 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
Europe: 144-146 MHz
USA: 144-148 MHz
Modulations
FM
RF-output
Hi 2.5 W, Lo 0.2 W

Connections

Antenna
BNC
Impedance
50 Ω
Other
-

Electrical

Power requirements
10.8V DC +/-10%
Current drain RX
45-150 mA
TX
250-800 mA

Physical

Dimensions (w×h×d)
68 × 181 × 54 mm (2.68 × 7.13 × 2.13 in)
Weight
680 gr (1.5 lbs)
Form factor
Unknown
Manufactured
Between 1979 and 19xx in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
Scanning. CTCSS option
Accessories
-
RigReference ID
4251
MPN
YAESU-FT-000207R

Manuals, diagrams and brochures

Yaesu FT-207R IM PDF - 10.04 MB, submitted by Berend

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FT-207R. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Yaesu FT-207R is around:

  • EUR 4.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2010 EUR 31.00 Used / Fair eBay
