General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
?
Memories
81 channels in 1 bank(s)

Receiver

RX-range
110-180 / 300-520 / 800-999 MHz
Modulations
AM   FM
Sensitivity
Main: 0.2 µV (12 dB SINAD)
Sub: 0.25 µV (12 dB SINAD)
Selectivity
15 kHz (-6 dB), 28 kHz (-60 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
>70 dB
Audio output
?

Transmitter

TX-range
144-146 MHz (Europe)
144-148 MHz (USA)
Modulations
FM
RF-output
High: 70 W, Mid1: 50 W, Mid2: 25 W, Low: 10 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
0.5-0.8 A
TX
Max 15 A

Physical

Dimensions (w×h×d)
140 × 40 × 180 mm (5.51 × 1.57 × 7.09 in)
Weight
1.25 kg (2.8 lbs)
Form factor
Mobile
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
DCS & ARTS
9K6 packet ready
Twin RX
Accessories
-
RigReference ID
4282
MPN
YAESU-FT-003000M

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FT-3000M. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Yaesu FT-3000M is around:

  • USD 119.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 USD 120.00 Used / Okay Hussain Alali
2020 USD 120.00 Used / Fair Essa
