Yaesu FT-411MKII

Handheld VHF Transceiver

Specs Manuals (0) Reviews (0) Prices (0) Compare

The Yaesu FT-411MKII is a handheld VHF transceiver. It covers 140-174 MHz in receive and 144-146 MHz (Europe) or 144-148 MHz (USA) in transmit. Tuning steps are selectable at 5 / 10 / 12.5 / 20 / 25 kHz. RF output is High: 2.5-5 W (depending on voltage), Low: ? W. It features 1 memory bank with 49 channels, VOX and CTCSS option (FTS-17A). Power requirements are 5.5-15V DC. Dimensions are 188 × 55 × 32 mm. Weight is 550 gr with FNB-11H battery. Current drain in receive is 7-150 mA and 1.3 A max. in transmit.

General characteristics

HAM bands: 2m
Frequency stability: ?
Tuning steps: 5 / 10 / 12.5 / 20 / 25 kHz
Memories: 49 channels in 1 bank(s)

Receiver

RX-range: 140-174 MHz
Modulations: FM
Sensitivity: Better than 0.16 µV (12 dB SINAD)
Selectivity: ?
Filters: ?
Receiver system: ?
IF-frequencies: ?
Image rejection: ?
Audio output: ?

Transmitter

TX-range: 144-146 MHz (Europe)
144-148 MHz (USA)
Modulations: FM
RF-output: High: 2.5-5 W (depending on voltage), Low: ? W

Connections

Antenna: BNC
Impedance: 50 Ω
Other: -

Electrical

Power requirements: 5.5-15V DC
Current drain RX: 7-150 mA
TX: 1.3 A max.

Physical

Dimensions (w×h×d): 55 × 188 × 32 mm (2.17 × 7.40 × 1.26 in) with FNB-11H
Weight: 550 gr (1.2 lbs) with FNB-11H
Form factor: Handheld
Manufactured: Between 198x and 19xx

Other features

Usage: Amateur / Ham radio operators
Features + options: VOX
CTCSS option (FTS-17A)
Accessories: -
RigReference ID: 4293
MPN: YAESU-FT-000411MKII

We do our best to be accurate, but if you've spotted something wrong or incomplete, please let us know!
